l low insertion loss and low pdl
l uniform power splitting
l high reliability
l excellent environmental stability
l compact size and various packages
l fttx systems
l digital hybrid and am-video systems
l catv systems
l other applications in fiber optic systems
performance specifications
* measured at room temperature and excludes connector loss
2×n plc splitter
type | 2x2 | 2x4 | 2x8 | 2x16 | 2x32 | 2x64 | |
fiber type | g657.a or customer appoint | ||||||
operating wavelength(nm) | 1260~1650 | ||||||
insertion loss(db) | max(p/s) | 3.9/4.3 | 7.5/7.8 | 11.0/11.3 | 14.2/14.5 | 17.3/17.6 | 21.0/21.3 |
loss uniformity(db) | max | 0.8 | 1.0 | 1.5 | 1.8 | 2.0 | 2.5 |
polarization dependent loss(db) | max | 0.3 | 0.3 | 0.32 | 0.35 | 0.4 | 0.4 |
fiber type and length (mt) | min | customized | |||||
directivity(db) | min | 55 | |||||
return loss(db) | min | upc:50 apc:55 | |||||
operating temperature(℃) | -40~85 | ||||||
storage temperature(℃) | -40~85 |
1×n plc splitter
type | 1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | |
fiber type | g657.a or customer appoint | ||||||
operating wavelength(nm) | 1260~1650 | ||||||
insertion loss(db) | max | 3.6/3.8 | 7.2/7.4 | 10.4/10.6 | 13.5/13.7 | 16.5/16.9 | 20/20.3 |
loss uniformity(db) | max | 0.6 | 0.8 | 0.8 | 1.1 | 1.5 | 2.0 |
polarization dependent loss(db) | max | 0.25 | 0.25 | 0.3 | 0.3 | 0.3 | 0.4 |
fiber type and length (mt) | min | input≦ 1.5mt outputs≦ 1.5 mt | |||||
directivity(db) | min | 55 | |||||
return loss(db) | min | p: 55db / s:50db | |||||
operating temperature(℃) | -40~85 | ||||||
storage temperature(℃) | -40~85 |
